DURACO SOLAR WATER HEATER 300L – split unit high pressure

Duraco solar water heaters are good for the environment. Some benefits include:  Fighting climate change Protecting air quality Protecting water quality Monthly savings Increased home value The Duraco Solar Water Heaters are made from the latest thermal technology known as Vacuum Tubes.The solar unit consists of a solar collector and a hot water storage tank. They have been designed and built to suit weather conditions similar to those prevailing in Mauritius. Split Unit Solar Water Heater (High Pressure) Specification • Inner tank material: SUS316 Thickness(mm): 1.2 • Outer tank: SUS316 • Insulation: polyurethane Thickness(mm): 45 • Incorporated electric booster: 1.5Kw,220V • Manifold connections (inch): 3/4 or 1 • Vacuum tube: QB-AL-N/AL-58-1800 • Frame: aluminum alloy Thickness (mm): 2.4 • Frame angle (Degree): 30 degrees • Test pressure (Bar): 10 • Operating fluid pressure (Bar): 4 • Max. service temperature (degree): 95• Max. stagnation temperature (degree): 250.3 • Distance from tube to tube (mm): 78 • Min. collector angle (degree): 15 • Max. Collector angle (degree): 75 • Max. distance advised between the collector and the hot water tank: 50 m • Region: Throughout Mauritius • Made in China • Warranty: 15 Years on Tube and Frame • The maximum distance between the tank and the panel is 50m (the more the distance, the higher the loss of efficiency) • The height of the tank 300L is 1754mm 8 Years on Tank
